AV-1280 LCD Controller Board

  • Panel compatibility: Compatible with 1280 x 1024 & 1024 x 768 TFT LCD’s from manufacturers such as Sharp, NEC, Toshiba, IBM, Samsun
  • Input voltage: 12VDC
  • Controller dimensions: 179mm x 114.3mm x 20mm(approx.)
  • Part number: 4163600-0X
  • Availability: End of life — no longer available

Jump to Downloads

Find on the Controller Solution Generator (CSG)

END OF LIFE — no longer manufactured

This page is kept as a reference for installed systems.

AV-1280 LCD Controller Board

The AV-1280 was a Digital View LCD controller board. This page is retained so that anyone maintaining an installed system can identify the board and reach its documentation.

Specifications: AV-1280

  • Panel compatibility: Compatible with 1280 x 1024 & 1024 x 768 TFT LCD’s from manufacturers such as Sharp, NEC, Toshiba, IBM, Samsung, Hitachi, LG, Fujitsu, Philips/Hosiden, Mitsubishi, etc. (subject to correct BIOS version being installed).
  • No. of colors: On 24 bits panel (3 x 8-bit): 16.7M colours On 18 bits panel (3 x 6-bit): 256k colors
  • Input auto-synchronization: NTSC, PAL & SECAM Factory default is PAL B, G, H, I and NTSC M Optional compatibility
  • Signal input termination: 10k or 75 ohm, jumper or OSD select
  • Standard video input: Composite and S-video RS-170 compatible
  • Function control methods: • Manual via buttons: 5 button. • Remote control via infra-red • RS-232 link option
  • Functions available: • On/Off - via mechanical switch, not OSD • Volume (audio option) • Brightness • Contrast, • Color • Tint (NTSC only) • Image position (V & H). • Input priority (Composite or S-video) • Image rotate and inverse
  • Functions display: On screen display of menu and settings
  • Power saving / Standby mode: If no signal input: • On screen message, timed • Auto power down
  • Image size control: Vertical & horizontal size adjustment to ensure full screen image.
  • Settings memory: Settings are stored in non volatile memory
  • Status indication LED: • Green for power on • Red for power down / standby
  • Controller dimensions: 179mm x 114.3mm x 20mm(approx.)
  • Voltage output for LCD: +3.3V DC, +5V DC, +12V DC
  • Input voltage: 12VDC
  • Power protection: Fuse fitted – auto reset
  • DC Power handling: Solid state
  • Power load maximum: The controller has an overall 3Amp current limit.
  • Controller power consumption: Approx. 2.5W (controller logic only, no panel)
  • Storage temperature limits: -40oC to +70oC
  • Operating temperature limits: 0oC to +60oC
  • Options: Dual channel audio amplifier & volume control

Downloads: AV-1280

Other documentation for this board may be available on request — contact us.
